Low-Capacitance CRESNET Plenum Cable – 2×22 AWG + 2×18 AWG, 500ft

Description

CRESNETPBKSP500

Cresnet® Control Cable PlenumRated Black 500 ft (152 m) spool

Crestron® certified for use in the wiring of a Cresnet® control network. Provides (1) 22 AWG shielded twisted pair for Cresnet control data and (1) 18 AWG pair for 24VDC and Ground within a single plenumrated jacket.

Data Pair
Colors Blue/white
Conductors (2) 22 AWG (0.33 mm²) stranded bare copper twisted
Insulation Foam FEP
Shield Aluminum/Polyester (100% coverage)
Drain (1) 24 AWG (0.20 mm²) stranded tinned copper
Capacitance 12.5 pF/ft (41 pF/m) nominal
Impedance 100 Ohms nominal
Power Pair
Colors Red/black
Conductors (2) 18 AWG (0.82 mm²) stranded bare copper
Insulation Plenum polymer
Shield none

Outer Jacket
Material Plenum polymer
Thickness 0.015 inch (0.381 mm) nominal
Outer Diameter 0.216 inch (5.487 mm) nominal
Color Options Black w/yellow stripe
